"""Leniax colormaps
"""
from __future__ import annotations
import copy
import json
import numpy as np
import logging
from matplotlib.colors import ListedColormap
from typing import List, Callable, Dict
from hilbertcurve.hilbertcurve import HilbertCurve
# This might be cool? https://bottosson.github.io/misc/colorpicker/#ce7d96
[docs]class PerceptualGradientColormap():
"""Perceptual gradient colormap
Attributes:
name: Colormap name
hex_bg_color: Background color (in hexadecimal)
hex_colors: List of colors used to create the perceptual gradient
cmap: Matplotlib ``ListedColormap``
"""
name: str
hex_bg_color: str
hex_colors: List[str]
cmap: ListedColormap
def __init__(self, name: str, hex_bg_color: str, hex_colors: List[str]) -> None:
"""Initialize the perceptual colormap
Args:
name: Colormap name
hex_bg_color: Background color (in hexadecimal)
hex_colors: List of colors used to create the perceptual gradient
"""
self.name = name
self.hex_bg_color = hex_bg_color
self.hex_colors = hex_colors
self.cmap = ListedColormap(hex_to_palette_rgba(hex_bg_color, hex_colors))
def __call__(self, data: np.ndarray) -> np.ndarray:
"""Apply the colormap
Args:
data: 1-channel data
Returns:
RGBA data of shape [nb_dims..., 1, C=4] and dtype float32
"""
return self.cmap(data)
def save(self) -> str:
"""Serialize the colormap
Returns:
A JSON string representing the colormap
"""
return json.dumps({
'name': self.name,
'hex_bg_color': self.hex_bg_color,
'hex_colors': self.hex_colors,
})
@staticmethod
def load(self, json_string: str) -> PerceptualGradientColormap:
"""Load a colormap
Args:
json_string: A JSON string representing the colormap
Returns:
The corresponding PerceptualGradientColormap
"""
raw_obj = json.loads(json_string)
return PerceptualGradientColormap(raw_obj['name'], raw_obj['hex_bg_color'], raw_obj['hex_colors'])
def print_uint8_rgb_colors(self):
"""Print the list of colors contained in the colormap"""
logging.info(np.array(np.array(self.cmap.colors) * 255, dtype=np.int32)[:, :3].tolist())
class Hilbert2d3dColormap():
"""Colormap using Hilbert curves
This Colormap use Hilbert curves to map a 2 channel image to a 3 channel one.
Attributes:
name: Colormap name
nb_pixels_power2: Number of pixels defined as a power of 2
nb_colors_power2: Number of colors defined as a power of 2
"""
name: str
nb_pixels_power2: int
nb_colors_power2: int
def __init__(self, name: str, nb_pixels_power2: int = 7, nb_colors_power2: int = 12):
"""Initialize the Hilbert 2d->3d mapping colormap
Args:
name: Colormap name
nb_pixels_power2: Number of pixels defined as a power of 2
nb_colors_power2: Number of colors defined as a power of 2
"""
self.name = name
self.nb_pixels_power2 = nb_pixels_power2
self.nb_colors_power2 = nb_colors_power2
self._populate()
def set_nb_pixels_power2(self, nb_pixels_power2: int = 7):
"""Set the number of pixels as a power of 2
Args:
nb_pixels_power2: Number of pixels defined as a power of 2
"""
self.nb_pixels_power2 = nb_pixels_power2
self._populate()
def set_nb_colors_power2(self, nb_colors_power2: int = 12):
"""Set the number of colors as a power of 2
Args:
nb_colors_power2: Number of pixels defined as a power of 2
"""
self.nb_colors_power2 = nb_colors_power2
self._populate()
def _populate(self):
H = W = 2**self.nb_pixels_power2
nb_pixels = H * W
pixel_colors_step_size = (2**(self.nb_colors_power2 - self.nb_pixels_power2))**2
hilbert2d = HilbertCurve(self.nb_pixels_power2, n=2)
hilbert3d = HilbertCurve(self.nb_colors_power2, n=3)
self._rgba_mapping = np.zeros([H, W, 4], dtype=np.float32)
self._max_h = self._rgba_mapping.shape[0] - 1
self._max_w = self._rgba_mapping.shape[1] - 1
for i in range(nb_pixels):
px_pos = hilbert2d.point_from_distance(i)
rgb = hilbert3d.point_from_distance(pixel_colors_step_size * i)
self._rgba_mapping[px_pos[0], px_pos[1]] = np.array(list(rgb) + [255]) / 255
def __call__(self, data: np.ndarray):
"""Apply the colormap
Args:
data: data of shape [nb_dims..., C=2] and dtype float32
Returns:
RGBA data of shape [nb_dims..., 1, C=4] and dtype float32
"""
assert data.shape[-1] == 2
ori_shape = data.shape
# Map data as 2d coordinates
data = data.reshape(-1, 2)
data[:, 0] = (data[:, 0] * self._max_h).round()
data[:, 1] = (data[:, 1] * self._max_w).round()
data = data.astype(np.uint8)
# Gather RGBA values
data = self._rgba_mapping[data[:, 0], data[:, 1]]
return data.reshape(list(ori_shape[:-1]) + [1, 4])
class ExtendedColormap():
"""Extended colormap
This colormaps simply extends less than 3 channels data into 4 channels RGBA data
Attributes:
name: Colormap name
transparent_bg: Set to ``True`` to make the background transparent.
"""
name: str
transparent_bg: bool
def __init__(self, name: str, transparent_bg: bool = False):
"""Initialize the perceptual colormap
Args:
name: Colormap name
transparent_bg: Set to ``True`` to make the background transparent.
"""
self.name = name
self.transparent_bg = transparent_bg
def __call__(self, data):
"""Apply the colormap
Args:
data: 1-channel data
Returns:
RGBA data of shape [nb_dims..., 1, C=4] and dtype float32
"""
c = data.shape[-1]
if self.transparent_bg is True:
a_layer = data.sum(axis=-1, keepdims=True)
a_layer[a_layer > 0.25] = 1
else:
a_layer = np.ones(list(data.shape[:-1]) + [1])
if c == 1:
g_layer = np.zeros(list(data.shape[:-1]) + [1])
b_layer = np.zeros(list(data.shape[:-1]) + [1])
data = np.concatenate([data, g_layer, b_layer, a_layer], axis=-1)
elif c == 2:
b_layer = np.zeros(list(data.shape[:-1]) + [1])
data = np.concatenate([data, b_layer, a_layer], axis=-1)
elif c == 3:
data = np.concatenate([data, a_layer], axis=-1)
else:
# In that case, we only keep the first 3 channels
data = np.concatenate([data[..., :3], a_layer], axis=-1)
return np.expand_dims(data, axis=-2)
#######
def all_channels(func: Callable) -> Callable:
def wrapper(channel, *args, **kwargs):
try:
return func(channel, *args, **kwargs)
except TypeError:
return list(func(c, *args, **kwargs) for c in channel)
return wrapper
def all_channels2(func: Callable) -> Callable:
def wrapper(channel1, channel2, *args, **kwargs):
try:
return func(channel1, channel2, *args, **kwargs)
except TypeError:
return list(func(c1, c2, *args, **kwargs) for c1, c2 in zip(channel1, channel2))
return wrapper
@all_channels
def to_sRGB_f(x: float) -> float:
''' Returns a sRGB value in the range [0,1]
for linear input in [0,1].
'''
return 12.92 * x if x <= 0.0031308 else (1.055 * (x**(1 / 2.4))) - 0.055
@all_channels
def to_sRGB(x: float) -> int:
''' Returns a sRGB value in the range [0,255]
for linear input in [0,1]
'''
return int(255.9999 * to_sRGB_f(x))
@all_channels
def from_sRGB(x: int) -> float:
''' Returns a linear value in the range [0,1]
for sRGB input in [0,255].
'''
x_f = x / 255.0
if x_f <= 0.04045:
y = x_f / 12.92
else:
y = ((x_f + 0.055) / 1.055)**2.4
return y
@all_channels2
def lerp(color1: float, color2: float, frac: float) -> float:
return color1 * (1 - frac) + color2 * frac
def perceptual_steps(color1: List[int], color2: List[int], steps: int) -> List[List[int]]:
gamma = .43
color1_lin = from_sRGB(color1)
bright1 = sum(color1_lin)**gamma
color2_lin = from_sRGB(color2)
bright2 = sum(color2_lin)**gamma
colors = []
for step in range(steps):
intensity = lerp(bright1, bright2, step / steps)**(1 / gamma)
color = lerp(color1_lin, color2_lin, step / steps)
if sum(color) != 0:
color = [c * intensity / sum(color) for c in color]
color = to_sRGB(color)
colors.append(color)
return colors
def calculate_luminance(color_code: int) -> float:
index = float(color_code) / 255
if index < 0.03928:
return index / 12.92
else:
return ((index + 0.055) / 1.055)**2.4
def calculate_relative_luminance(rgb: List[int]) -> float:
return 0.2126 * calculate_luminance(rgb[0]) + 0.7152 * calculate_luminance(rgb[1]
) + 0.0722 * calculate_luminance(rgb[2])
def check_ratio(rgb1: List[int], rgb2: List[int]) -> int:
light = rgb1 if sum(rgb1) > sum(rgb2) else rgb2
dark = rgb1 if sum(rgb1) < sum(rgb2) else rgb2
contrast_ratio = (calculate_relative_luminance(light) + 0.05) / (calculate_relative_luminance(dark) + 0.05)
if contrast_ratio < 4.5:
return 0
if contrast_ratio >= 4.5 and contrast_ratio < 7:
return 1
else: # contrast_ratio >= 7
return 2
#####
def hex_to_rgba_uint8(hex: str) -> List[int]:
hex = hex.replace('#', '')
return [int(hex[i:i + 2], 16) for i in (0, 2, 4)] + [255]
def hex_to_palette_rgba(hex_bg_color: str, hex_colors: List[str]) -> np.ndarray:
steps = 254 // (len(hex_colors) - 1)
palette_rgb_uint8 = []
for i in range(0, len(hex_colors) - 1):
rgb1_uint8 = hex_to_rgba_uint8(hex_colors[i])[:3]
rgb2_uint8 = hex_to_rgba_uint8(hex_colors[i + 1])[:3]
palette_rgb_uint8 += perceptual_steps(rgb1_uint8, rgb2_uint8, steps)
fg_palette_rgba_uint8 = [rgb + [255] for rgb in palette_rgb_uint8]
# Transparent background
if hex_bg_color == '':
bg_rgba_uint8 = [0, 0, 0, 0]
else:
bg_rgba_uint8 = hex_to_rgba_uint8(hex_bg_color)
bg_rgba = np.array([bg_rgba_uint8]) / 255.
fg_palette_rgba = np.array(fg_palette_rgba_uint8) / 255.
palette_rgba = np.vstack([bg_rgba, fg_palette_rgba])
return palette_rgba
colormaps: Dict[str, Dict] = {
'alizarin': {
'name': 'alizarin',
'hex_bg_color': "#d6c3c9",
'hex_colors': ['f9c784', 'e7e7e7', '485696', '19180a', '3f220f', '772014', 'af4319', 'e71d36'],
'type': 'perceptual',
},
'black-white': {
'name': 'black-white',
'hex_bg_color': '#000000',
'hex_colors': ['ffffff', 'd9dbe1', 'b6b9c1', '9497a1', '737780', '555860', '393b41', '1f2123'][::-1],
'type': 'perceptual',
},
'carmine-blue': {
'name': 'carmine-blue',
'hex_bg_color': '#006eb8',
'hex_colors': ['#006eb8', '#fff200', '#cc1236'],
'type': 'perceptual',
},
'cinnamon': {
'name': 'cinnamon',
'hex_bg_color': '#a7d4e4',
'hex_colors': ['#a7d4e4', '#71502f', '#fdc57e'],
'type': 'perceptual',
},
'city': {
'name': 'city',
'hex_bg_color': '#F93943',
'hex_colors': ['ffa600', 'fff6e6', 'ffca66', '004b63', 'e6f9ff', '66daff', '3a0099', '23005c'][::-1],
'type': 'perceptual',
},
'golden': {
'name': 'golden',
'hex_bg_color': '#b6bfc1',
'hex_colors': ['#b6bfc1', '#253122', '#f3a257'],
'type': 'perceptual',
},
'laurel': {
'name': 'laurel',
'hex_bg_color': '#381d2a',
'hex_colors': ['ffbfd7', 'ffe6ef', 'ff80b0', '71bf60', 'eaffe6', '96ff80', 'bffbff', '60b9bf'][::-1],
'type': 'perceptual',
},
'msdos': {
'name': 'msdos',
'hex_bg_color': '#0c0786',
'hex_colors': ['#0c0786', '#7500a8', '#c03b80', '#f79241', '#fcfea4'],
'type': 'perceptual',
},
'pink-beach': {
'name': 'pink-beach',
'hex_bg_color': '#f4777f',
'hex_colors': ['00429d', '4771b2', '73a2c6', 'a5d5d8', 'ffffe0', 'ffbcaf', 'cf3759', '93003a'][::-1],
'type': 'perceptual',
},
'rainbow': {
'name': 'rainbow',
'hex_bg_color': '#000000',
'hex_colors': ['#FF0000', '#FF7F00', '#FFFF00', '#00FF00', '#0000FF', '#2E2B5F', '#8B00FF'],
'type': 'perceptual',
},
'rainbow_transparent': {
'name': 'rainbow_transparent#',
'hex_bg_color': '#000000',
'hex_colors': ['#FF0000', '#FF7F00', '#FFFF00', '#00FF00', '#0000FF', '#2E2B5F', '#8B00FF'],
'type': 'perceptual',
},
'river-Leaf': {
'name': 'river-Leaf',
'hex_bg_color': "#80ab82",
'hex_colors': ['4c5b5c', "ff715b", "f9cb40", "bced09", "2f52e0", "99f7ab", "c5d6d8", "7dcd85"][::-1],
'type': 'perceptual',
},
'salvia': {
'name': 'salvia',
'hex_bg_color': '#b6bfc1',
'hex_colors': ['#b6bfc1', '#051230', '#97acc8'],
'type': 'perceptual',
},
'summer': {
'name': 'summer',
'hex_bg_color': '#ffe000',
'hex_colors': ['003dc7', '002577', 'e6edff', '6695ff', 'ff9400', '995900', 'fff4e6', 'ffbf66'][::-1],
'type': 'perceptual',
},
'white-black': {
'name': 'white-black',
'hex_bg_color': '#ffffff',
'hex_colors': ['#ffffff', '#000000'],
'type': 'perceptual',
},
'extended': {
'name': 'extended',
'transparent_bg': False,
'type': 'extended',
},
'extended_transparent': {
'name': 'extended',
'transparent_bg': True,
'type': 'extended',
}
}
def get(name: str) -> PerceptualGradientColormap:
assert name in colormaps, f"Colormap {name} does not exist"
colormap_template = copy.deepcopy(colormaps[name])
ctype = colormap_template['type']
del colormap_template['type']
if ctype == 'extended':
return ExtendedColormap(**colormap_template) # type: ignore
elif ctype == 'perceptual':
return PerceptualGradientColormap(**colormap_template) # type: ignore
else:
raise ValueError(f"Colormap type {ctype} unknown")
